Highlead GM900 Overlock Sewing Machine High Speed Series



Highlead GM900 high speed overlock sewing machine with built-in direct drive motor. High speed overlocking model for stitching light to medium weight materials. Suitable for general purpose use in manufacturing a wide range of clothing & textiles, with the ability to produce a well balanced stitch formation and top quality seam finishes. The operating speed is adjustable up-to 7000 r.p.m (subject to material type & settings) via the built in operator control panel. With up-to 60% energy savings when compared to older style V-belt driven overlocker models. The high efficiency built-in direct drive motor operates quietly with greater speed control for the operator. The use of high specification assemblies and bearings, offers smooth running performance with a lighter more user friendly operation feel. Stitch length and fine differential feed amounts are easy to adjust and set. A needle area LED light is also included as standard equipment.


GM900-4Z = 4 thread industrial overlock sewing machine model

Features: Direct Drive motor system High speed drive assemblies & bearings. Fully automatic enclosed oil system with filter Silicone needle cooling device Differential feed adjusting lever Dial adjusting stitch regulator Top & bottom edge trimming knives. LED needle area light Built in control panel for easy speed adjustment	Specification: Max sewing speed: 7000spm Stitch length: up-to 3.8mm Stitch width: 4mm Presser foot lift: 5.5mm Differential ratio: 0.7 - 2 Needle standard B27 Other specs. subject to sub-class

GM900-3Z 3 thread overlock (general purpose)
GM900-4Z 4 thread overlock (general purpose)
GM900-3Z-15 narrow edge overlock (curled edge overlock)
GM900-ME1 Metered Elastic overlock (special purpose)
